Poly Studio P21 Personal Meeting Display

Personal Meeting Display

Poly Studio P21 personal meeting display makes it simple and easy to set up a premium video conferencing experience in your personal workspace. One device delivers the complete experience, including display, camera, microphone and speakers, with a single USB connection to your PC or Mac so it can be used with any video app. Exceptional camera optics complement dynamic, adjustable built-in lighting so you are confident you look your best. The enterprise-grade display delivers exceptional brightness and vibrant colors, while legendary Poly audio ensures you can hear and be heard clearly. For IT, Poly Lens cloud management provides robust tools to manage and track devices from anywhere.

Supercharge Your Video Calls – Look and Sound Insanely Good

Supercharge your video calls with the Poly Studio P21. Everything you need for a pro-grade video experience is ready to go with a single USB connection that works with any video app. A brilliant 21″ display and built-in high definition camera, hi-fidelity speakers, microphone and adjustable ambient lighting will make you look and sound crazy good.

See What You’ve Been Missing – Get A Sharp, Vibrant Display That Makes Your World Clearer

The pro-grade conferencing display delivers exceptional brightness and vibrant colors. You will no longer miss facial cues or spreadsheet details. And it makes an awesome second or backup display when not on video calls.

Never Miss A Beat – Advanced Microphone And Speakers Deliver Amazing Audio

Rich full-fidelity stereo speakers ensure you’ll never miss a word. And the advanced microphone delivers confidence that you’re always heard loud and clear. No shouting required.

The Freedom To Work How You Want – Works With Any Video App

There’s nothing to learn. The Poly Studio P21 works with the video apps you already know. A simple USB connection to your PC or Mac will transform your video conferencing experience. Volume and mute buttons ensure control is always within reach without fumbling for your mouse.

We Put You In The Best Light – Built-In Lighting Illuminates You Clearly

With dynamic, adjustable built-in lighting, you can count on looking your best and brightest in any light.

---

Poly Studio P21 Features:

• Exceptional camera optics and privacy shutter
• High performance enterprise grade display
• Adjustable dynamic ambient lighting
• Integrated stereo speakers and microphone
• Wireless mobile phone charging

---

Poly Studio P21 Personal Meeting Display Specifications:

Display

• 21.5 in LCD monitor
• Fixed 1080p FHD resolution (1920 x 1080), 16:9
• Contrast Ratio: 1000:1 (Typical)
• Viewing Angle: 89 degrees (Typical)
• Color Depth: 16.7M colors
• Pixel Pitch: 0.24795mm x 0.24795mm
• RoHS/Halogen Free

Ambient Lighting

• CRI 80/CCT  – 3000K
• Ambient Light Sensor (enabled with future software release)
• Capacitive touch control for vanity lighting

Camera

• 1080p (Full HD), 720P (HD) Compatible
• Max 80° DFOV
• Electronic Zoom up to 4x / EPTZ
• Low light quality & true color images
• Manual pan, tilt and zoom control through Poly Lens Desktop Application

Audio

• Microphone:
  • Single uni-directional MEMS microphone for focused pickup with noise and reverberance rejection
  • -26dB sensitivity, 65dB FS SNR
  • 50 Hz to 20 kHz frequency response
• Speakers:
  • Dual stereo speakers
  • 80 Hz to 20 kHz frequency response
  • 10W per Channel

Interfaces

• 1x USB-C 3.0 port (with 2.0 compatibility)
• 2x USB-A 3.0 ports
• Power connector
• Kensington security lock
• 3.5mm, 4-pole North America

Power Requirements

• External DC power supply: 120/240V, 80W
• Typical operation voltage/power:
  • 20W (no vanity lighting and no wireless charging)
  • 35W (normal; no wireless charging)
  • 50W (maximum; full volume, max brightness, wireless charging)
  • Sleep Mode ≤ 0.8 W
  • Off mode ≤ N/A
  • Typical operating BTU/H: = > 170.6

System Requirements

• Native support for Windows 8.1, 10
• Native support for MacOS 10.14.6 or higher

Device Driver Support

• USB 2.0/3.0/3.1
• UVC/UAC Plug and Play Compatible
• DisplayLink USB Graphics SW: 4.3.1 for MacOS version 10.13.4 to 10.14
• DisplayLink USB Graphics SW: 5.0.1 for MacOS 10.14.2 and newer

Poly Studio P21 Personal Meeting Display Compatibility

• Compatible with any application that supports standard USB/UVC standards

Manageability

• Cloud: Poly Lens service
• Local (Windows/Mac): Poly Lens Desktop App

Other Features

• Integrated privacy shutter
• Wireless mobile phone charging
• Volume Up/Down and mute controls, plus programmable button
• Microsoft Teams/Zoom app button (enabled with future software release)
• USB-A ports built-in for wireless headset adapter or other peripherals as USB hub, 5W charging capability
• Active call and mute status LED, with integration to select app partners

General

• Dimensions: 22.64 in(W) x 7.4(D) x 18.82(H)
• Weight: 15 pounds
• Temperature
  • Operating: 0° C to +40° C ambient at sea level
  • Storage: -40° C to +70° C at sea level
• Humidity
  • Operating: 15-80%, non-condensing at sea level
  • Non-Operating: 5% to 95%, non-condensing at sea level
• Altitude
  • Operating: -50 up to 10,000 ft
  • Non-Operating: -50 up to 35,000 ft
• Warranty: 2-years
• Poly+ enhanced support available
• SKU: 2200-87100-001
• Part # PPP21-1

---

What Comes In The Poly Studio P21 Personal Meeting Display Box:

• Poly Studio P21 personal meeting display
• USB-C to USB-C/USB-A adapter cable (1M)
• Power supply rating: 120/240V 80W
• Power Cord
• Desktop stand/base
• Two mounting setup sheets for optional components
• Safety Insert
• Warranty Information
• Lens Desktop Coaster

Optional Items

• VESA/wall mount
• Replaceable plastic speaker grill
